Compared to U type sheet piles, Z Sheet Piles could provide a larger section modulus with lower material cost (lower weight)， which is much more economic than traditional U sheet piles. One advantage of Z Sheet Piles is that during installation, the flange of the pile will be on the same line, which will be very convenient for the installation of waling beams.
Z Sheet Piles could be delivered in single pile, double pile (loose) and double pile with tack welding(crimped) / full welding form.
Product Production Range:
Thickness: 4-16mm
Length: Not limited, as per buyer's request.
Now 800mm and 850mm wideZ Sheet Piles are available in our mill, which will provide certain section modulus with a lower unit weight per square meter. Customized designs are also available and welcomed in our company.
Coating and anti-corrosion job is also available for Z sheet piles in our mill.
Material: Q235B, Q345B, S235, S240, SY295, S355, S430, S460, A690, ASTM A572 Grade 50, ASTM A572 Grade 60. All Chinese Standard, EN Standard, ASTM Standard and other standard material are available on request.
Manufacturing & Inspection Standard: EN10249-1 / EN10249-2
